NL2090 Master
Die-Cast Aluminium Bostäder
ALLMÄN INFORMATION
| Monteringsmodul | Post top or side entry from 25-450 Post top or side entry from 42- 600 Post top or side entry from 60-760 (optional) Spigot entry 100mm |
| Monteringsmodul Tilt Angles | Post top/side entry O, +-5,+-10, +-15 |
| Driftstemperatur | -40°C / +55°C |
| Förvaringstemperatur | -40°C / +80°C |
| Glass Mounting Options | Capsule mounting system Tool-free elips system (optional) |
| LED-moduler | Removable / Replaceable optical unit |
| Objektivalternativ | COL 1530 (standard) Project-specific lens selection |
| Huvudreferens Företagets riktlinjer | EN fiZ117, EN 62722-1, EN 62722-2-1, EN 60596-1, EN 60596-2-3, EN 62471, EN 60068-2-TI, EN60068-2-52, IS092Z7,A51MBTI7,A51MD3359-78, 1504628-2, 150 4628-4, EN f,()529, EN 62262,ANSI036.10-20l7, ANSI036.2-2018, EN 62031, IEC 62384,A51MD3359, EN 1502409, IES LM 80-15,IES lM 82-12, IES LM 84-14, IES LM 85-14, LM 79-19, IESlM 21-TI, CE, RoHS, 1S0900I, 1S01400I, ISOlBOOI, ISOSOOI, 1504500I, IS039001, EAC, TIJRKAK |
ELEKTRISK INFORMATION
| Elkurs | Class I, Class II (optional |
| Nominell spänning | 220-240V 50 / 60 Hz EU 110-277V 50 / 60 Hz (optional) NORTH AMERICA |
| Ljusström | 350mA, 500mA, 700 mA , 925 mA, 1050 mA |
| Effektfaktor | ≥0.9 (at full load) |
| Förare | Constant current, thermal protected, voltage regulated, harmonic filter protection |
| Surge protection options (kV) | 6 Kv (standard) 10 kV (optional) with LED signal and thermo fuse ta disconnect load at the end of life 20 kV (optional) with LED signal and thermo fuse ta disconnect load at the end of life |
| Styrsystem | On-off (standard), Bluetooth, DALI, 1-10V DIM, stand alone automation |
| Uttag | NEMA 4-pin (ZHAGA book 78) (optional) NEMA S-pin (ANSI Cl36.41) (optional) NEMA 7-pin (ANSI Cl36.41) (optional) |
| Sensor | PIR (optional), Photocell (optional), Daylight (optional) |
| Mains connection | Far cable max section 2,5 mm2 Outgoing cable H05RN-F 2/3/5 x 7,5 mm2 Length on request.(optional) |
| Electromagnetic compatibility (EMC) | IEC 61000, EN 55015, IEC 61000-3-2, IEC 61000-4-5, IEC 61547, IEC 61000-3-3, IEC 61000-4-2, IEC 61000-2-2, IEC 61000-4-11, IEC 61643-11 |
BOENDE OCH MATERIAL
| Bostäder | Non corressive high pressure die-cast aluminium |
| Optic | PMMA or PC |
| Gasket | Silicon or polyurethane without junction points. |
| Bostäder Finish | UNI EN1706 powder painted |
| Refractor | Tempered glass min. 4mm high transparecy UV resistant (optional) |
| Cable Gland | IP66 ,Plastic PG9, IP67 (optional), IP68 (optional) |
| Standard Colour | RAL7021 Metalic |
| Tightness Level | IP66, IP67 (optional), IP68 (optional) |
| Impact Bostäder Resistance | IK10 (20 J) |
| Impact Glass Resistance | IK08 (5 J), IK09 (optional) (10 J), IK10 (optional) (20 J) |
| Vibration Test | Compliant with modified IEC 68-2-6 (0.5G), ANSI C136.31 (3G-5G |
OPTISK INFORMATION
| Led colour temperature | 2700K (warm white), 3000K (warm white), 4000K (neutral white) (standard), 5000K (cool white), 5700K (cool white), 6500K (cool white), Other (amber, blue, green, red) |
| Colour rendering ındex (CRI) | CRI ≥70, CRI ≥80 (optional), CRI ≥90 (optional) |
| Upward light output ratio | 0% |
| Photobiological safety class | IEC 62471, EN 62778 EXEMPT GROUP |
| Testing standard | LM 79-19 , EN 13032-1 (all measurements in ISO17025 accredited laboratory) |
| Lifetime of the LED's | Tq= 25 °, 700 Ma 187.000h - L90810 Tq= 55 °, 700 Ma 156.000h - L90810 |
